Product Details:
|
| Materials: | Bellows 316L, Shell 304 | Construction: | All Stainless Steel |
|---|---|---|---|
| Highlight: | Shell 304 Vacuum Valves,Stainless Steel Vacuum Valves,Bellows 316L vacuum valve |
||
Specifications
●Bakeability: 400℃(open), 300℃(close)
●Pressure Range: Below 10-10 torr
●All stainless steel construction
●Bellows stem seal
●Leak Rate: 8.7x10-11 Pa.m3/sec
●Closure Torque: CR16 First 150kg-cm, Maximum 250kg-cm
CR35 First 300kg-cm, Maximum 600kg-cm
●Orientation: Any position
